BAR执行器GS-125/090-11-F07/F10-V22-H

BAR生产和销售气动和电动执行器以及成套自动阀门和各种配件。BAR一直致力于工厂建设和工业过程相关应用的产品开发和创新。

BAR执行器GS-125/090-11-F07/F10-V22-H技术参数

BAR执行器GS/GD系列介绍

由于有18种不同的尺寸和扭矩从2到13.040 Nm，因此可以为截止阀的每种应用提供合适的旋转执行器。

盖帽和外壳的高品质粉末涂层由硬涂层铝制成，即使在恶劣的环境条件下也能使用。

电磁阀接口位于型材的高处，易于接近，从而优化了先导阀的安装。

电磁阀连接另一侧的终端位置调整方便了调整过程。

标准化接口 VDI/VDE 3845 可用于设置所有商用信号和控制设备。

位置指示器是产品的一部分，它配备了用于显示阀门位置的可变夹子。

终端位置可以配置在0°到90°以及+ 5°到-5°之间，从而可以对阀门进行*佳调整。

每个执行器尺寸的大多数尺寸都有2种ISO法兰模式，以确保阀门的灵活自动化。

八角小齿轮连接适应阀门的平行或对角选择轴对准，并确保节省空间的执行器结构。

安全弹簧的组装和拆卸简单，设计用于平衡气动扭矩和弹簧扭矩之间的比例。

每个控制压力都分配给定义数量的弹簧，并有助于根据扭矩选择执行器。

执行器外壳上的激光雕刻标记了法兰图案和空气连接，以便明确分配。

序列号也是激光雕刻的；这有助于随时跟踪执行器的制造情况。

精确研磨的活塞齿系统可确保更平稳的运行、*佳扭矩和低磨损。

所有运动部件均采用滑动轴承，使用寿命长。

由于具有不同旋转角度的执行器变体，执行器涵盖了广泛的应用。

通过为单作用和双作用执行器使用相同的盖子来减少库存水平。

A suitable rotary actuator is available for each application of shut-off valves due to 18 different sizes and torques from 2 to 13.040 Nm.

The high-quality powder coating of the cap and housing made of hard-coated aluminium allows the usage even in aggressive environmental conditions.

The solenoid valve interface is located high on the profile and easily accessible which optimizes the installation of pilot valves.

The end position adjustment on the opposite side of the solenoid valve connection facilitates the adjustment process.

The standardised interface VDI/VDE 3845 can be used to set up all commercially available signal and control devices.

The position indicator is part of the product which is equipped with variable clips for displaying the valve position.

The end positions can be configured between 0° and 90° as well as from + 5° to -5°, whereby the valve can be optimally adjusted.

There are 2 ISO flange patterns available for most of the sizes per each actuator size to ensure flexible automation of valves.

The octagonal pinion connection adapts a parallel or diagonal selector shaft alignment of the valve and ensures a space-saving actuator construction.

Simple assembly and disassembly of the safety springs which are designed for a balanced ratio between pneumatic torque and spring torque.

Each control pressure is assigned to a defined number of springs and facilitates the actuator selection based on the torques.

A laser engraving on the actuator housing marks the flange patterns and air connections for a clear allocation.

The serial number is also laser engraved; this helps to trace the actuator manufacturing at any time.

Precisely milled piston tooth system ensures smoother running, optimum torque and low wear.

A long service life is achieved by using the plain bearing for all moving parts.

The actuators cover a wide range of applications thanks to the actuator variants with different swivel angles.

A reduced stock level is achieved by using identical caps for single- and double-acting actuators.

BAR执行器GS/GD系列其他常用型号：

BAR GS-075/090-07-F05/07-V14F

BAR GS-125/090-11-F07/F10-V22-H

BAR GS-032

BAR GS-040

BAR GS-052

BAR GS-063

BAR GS-075

BAR GS-083

BAR GS-092

BAR GS-105

BAR GS-125

BAR GS-140

BAR GS-160

BAR GS-190

BAR GS-210

BAR GS-240

BAR GS-270

BAR GS-300

BAR GS-350

BAR GS-400
