BUSAK+SHAMBAN(B+S)金属防尘封WM0000700-N7M5

TRELLEBORG特瑞堡密封系统成立于1952年，已收购德国BUSAK+SHAMBAN。

BUSAK+SHAMBAN(B+S)金属防尘封WM0000700-N7M5产品参数

BUSAK+SHAMBAN(B+S)金属防尘封WM系列产品介绍及选型

The metal scraper is a single-acting special scraper with two different scraper lips - a thin metallic lip and a elastomer lip. The two scraper lips are arranged in tandem behind one another in a compact metal housing.

The metal scraper lip is designed to remove firmly adhering soiling and ice particles. The secondary lip of elastomer material enhances the overall scraping effect, i.e. fine sand grains, water and similar foreign matter are reliably scraped off. Both scraper lips have a smaller diameter than the nominal diameter of the piston rod, thus ensuring a tight fit of the scraper lips. The metallic lip is guided flexibly in radial direction and can easily follow any possible deflections of the piston rod.

Advantages

- Very good scraping effect, even with firmly adhering dirt, e.g. mud, ice

 - Very abrasion resistant

 - Tight fit in the groove due to the metal case

 - Easy installation in open grooves

echnical Data

Speed: Max. 1 m/s with reciprocating movements

Temperature: -30 °C to +120 °C

Media: Mineral oil-based hydraulic fluids, flame retardant hydraulic fluids (HFA, HFB, HFC), water, air, etc.

金属刮刀是一种单作用的特殊刮刀，带有两个不同的刮唇——一个薄金属唇和一个弹性唇。两个刮刀唇在一个紧凑的金属外壳中串联排列。

金属刮刀唇设计用于去除牢固粘附的污垢和冰粒。弹性体材料的副唇增强了整体刮削效果，即细砂粒、水和类似异物被可靠地刮掉。两个刮唇的直径都小于活塞杆的公称直径，从而确保刮唇的紧密配合。金属唇沿径向灵活引导，可以轻松跟随活塞杆的任何可能偏转。

好处

 - 非常好的刮削效果，即使是牢固粘附的污垢，例如泥、冰

 - 非常耐磨

 - 由于金属外壳，紧密配合凹槽

 - 易于安装在开槽中

技术资料

速度：往复运动时*大 1 m/s

温度：-30 °C 至 +120 °C

介质：矿物油基液压油、阻燃液压油（HFA、HFB、HFC）、水、空气等。

BUSAK+SHAMBAN(B+S)金属防尘封WM系列其他常见型号：

BUSAK+SHAMBAN WM0000650

BUSAK+SHAMBAN WM0000700

BUSAK+SHAMBAN WM0000750

BUSAK+SHAMBAN WM0100800

BUSAK+SHAMBAN WM0000850

BUSAK+SHAMBAN WM0000900

BUSAK+SHAMBAN WM0000950

BUSAK+SHAMBAN WM0001000

BUSAK+SHAMBAN WM0001100

BUSAK+SHAMBAN WM0000700-N7M5
