爱泽工业2023年3月部分到货产品专题及库存——REGO，GENERANT泄压阀篇

如下为我司爱泽工业IZE_Industries本月到货REGO和GENERANT相关产品，欢迎致电索取样本资料和产品信息。




REGO阀3125L




GENERANT阀VRV125B-T-10




GENERANT阀VRV125B-T-15

REGO阀3125系列介绍
应用
专为保护可能会截留液态液化石油气或无水氨的管道和截止阀而设计。 它们可以安装在位于截止阀之间或 RegO 截止阀的侧凸台中的管道和软管中。

特征
• 泄压阀设计为在排放后自动重新固定牢固。
• 弹性阀座圆盘提供“无气泡”密封。
• 有黄铜和不锈钢两种材质可供选择。
• 可提供在需要时允许直接连接排气管道的配置。

Application
Designed especially for the protection of piping and shut-off valves where there is a possibility of trapping liquid LP-Gas or anhydrous ammonia. They may be installed in pipelines and hoses located between shut-off valves or in the side boss of RegO shut-off valves.

Features
• Relief valve designed to automatically reseat firmly after discharge.
• Resilient seat disc provides a “bubble-tight” seal.
• Available in both brass and stainless steel.
• Available in configurations that permit direct attachment of vent piping when required.

GENERANT阀VRV系列介绍及选型
一种紧凑、高精度、直接作用的泄压阀。 出厂预设为所需的开启压力和/或流量规格。 内部调节提供防篡改安全性，防止无意的压力变化。 可用黄铜、铝和 316 不锈钢制成的通向大气或内联配置的通风口。 阀门采用四环密封件，可通过狭窄的重新密封带提供极高的精度和可重复性。 可选的偏转盖增加流量并提供排放偏转。

A compact, highly accurate, direct acting pressure relief valve. Factory preset to desired crack pressure and/or flow specifications. Internal adjustment provides tamper proof safety against inadvertent pressure changes. Available vent to atmosphere or inline configurations in brass, aluminum and 316 stainless steel. Valves feature a Quad ring seal which provides for extreme accuracy and repeatability with a narrow reseal band. Optional deflector cap increases flow capacity and provides for deflection of discharge.



GENERANT安全阀CRV系列介绍
The Generant Series Stainless Steel CRV, Cryogenic Relief Valve is a spring reference over pressure protection device. The Stainless CRV is supplied cleaned and packaged for oxygen service making it an ideal choice for most cryogenic relief valve applications. The valve can be ordered with set pressures ranging from 10 to 750 PSIG (0.69 to 51.7 Bar) and come factory preset and permanently locked. Relief pressure cannot be altered or adjusted in the field. Seat and poppet geometry combined with optimized spring ranges provide high flow rates with minimum pressure accumulation. Compact design and availability of a variety of inlet and outlet configurations reduces size and piping requirements. Relief pressure can be discharged to atmosphere or to a downstream connection. The CRV can be specified with PCTFE or PTFE for set pressures above 50 PSIG (3.45Bar), Fluorosilicone for set pressures below 50 PSIG, and FKM (Viton™) throughout the available set pressure range.

Features
• Available in NPT, Metal to Metal Face Seal and Bi-Lok Dual Ferrule Tube Connections
• High Flow Capacity and Excellent Reseal Performance
• Discharge to Atmosphere or a Wide Varity of Inline Piping Configurations
• Supplied Factory Preset Set and Permanently Locked for Tamper Proof Service
• 100% Factory Tested for Leakage, Crack and Reseal Performance
• Optional Deflector Cap available for diverting exhausted gas
• Cleaned and Packaged for Oxygen Service

Generant 系列不锈钢 CRV 低温安全阀是一种弹簧参考过压保护装置。不锈钢 CRV 提供清洁和包装用于氧气服务，使其成为大多数低温安全阀应用的理想选择。可订购设定压力范围为 10 至 750 PSIG（0.69 至 51.7 巴）的阀门，出厂预设并永久锁定。不能在现场改变或调整释放压力。阀座和提升阀几何形状与优化的弹簧范围相结合，可提供高流量和*小的压力积累。紧凑的设计和各种入口和出口配置的可用性降低了尺寸和管道要求。释放压力可以排放到大气中或排放到下游连接。 CRV 可以指定为设定压力高于 50 PSIG (3.45Bar) 的 PCTFE 或 PTFE，指定压力低于 50 PSIG 的氟硅橡胶，以及整个可用设定压力范围内的 FKM (Viton™)。

特征
• 提供 NPT、金属对金属面密封和 Bi-Lok 双卡套管连接
• 高流量和出色的再密封性能
• 排放到大气或各种内嵌管道配置
• 提供工厂预设并永久锁定以提供防篡改服务
• 100% 的泄漏、开裂和重新密封性能经过工厂测试
• 可选的导流帽可用于转移废气
• 针对氧气服务进行清洁和包装

REGO / GENERANT阀常用型号：
REGO 3127K
REGO 3129K
REGO 3125L
REGO 3127L
REGO 3129L
REGO SS8001L
REGO SS8002L
REGO SS8021L
REGO SS8022L
REGO 3127U
REGO 3129U
GENERANT VRV125B-T-10
GENERANT VRV125B-T-15
GENERANT VRV250B-T-10
GENERANT VRV375B-T-10
GENERANT VRV500B-T-10
GENERANT VRV750B-T-10
GENERANT VRV1000B-T-10
GENERANT CRV8-8-K-203
GENERANT CRV8-8-K-348
GENERANT CRV8-8-K-131
GENERANT CRV8-8-K-740

如果您需要完整的REGO和GENERANT的相关技术咨询，请随时致电爱泽工业，或者访问网站，我们将尽全力解决您的问题。
