爱泽工业2023年9月部分到货产品专题及库存——MicroE篇

如下为我司爱泽工业IZE_Industries本月到货MICROE相关产品，欢迎致电索取样本资料和产品信息。


MICROE编码器M20


MICROE编码器MII6510-AB-400-1-1-0


MICROE编码器CE300


MICROE编码器195-00296


MICROE光栅尺TS-0001


MICROE编码器MII5510-AB-200-2-1


MICROE编码器MII1630S-40


MICROE编码器MII1600-40

MICROE编码器M1000系列介绍及选型
MicroE Mercury 1000 套件编码器比其他编码器更小、性能更高、安装速度更快且更易于使用。该微型传感器适合非常狭小的空间，并具有广泛的对准公差，可实现快速、轻松的设置。

• 微型传感器适合狭小空间
• 宽对准公差使安装和设置变得容易
• 模拟输出可由客户的电子设备进行插值，分辨率高达 78nm
• 低功耗有助于系统的热稳定性

MicroE Mercury 1000 kit encoders are smaller, higher performance, faster to install, and easier to use than any other encoder. The tiny sensor fits into very tight spaces, and has broad alignment tolerances for fast and easy setup.

• Miniature sensor fits into tight spaces
• Wide alignment tolerance make for easy installation and setup
• Analog outputs can be interpolated by the customer’s electronics for resolution up to 78nm
• Low power consumption aids in thermal stability of the system



MICROE编码器MII6000系列介绍及选型
Mercury II 6000 (MII6000) 系列编码器代表了性能上的突破，提供更高分辨率和精度、数字输出、更小的传感器尺寸、更强的多功能性、坚固性、智能可编程功能和易于安装。

系统功能
• Mercury II 6000 系列编码器包括：
- MII6500/6700/6800 - A-quad-B 输出
- MII6800Si/Pa（Pa - Panasonic）- 高速串行接口
• 适用于 Panasonic MINAS A4 和 A5 系列伺服驱动器的串行接口（用于线性轴）
• 直接来自传感器的高分辨率内插数字输出； 分辨率从 5μm 到 1.2nm
• 更低的循环误差 - 仅 ± 20nm - 提供平滑的速度控制
• 小型传感器 - 8.2 毫米高的传感器适合狭小空间 (8.1 毫米 – 6000V)
• 速度更快 - 分辨率为 0.1µm 时速度高达 5m/s (MII6000)。 分辨率为 1.2nm 时高达 10 m/s (MII6800Si/Pa)
• 更智能 - MII6000 的可编程分辨率以整数步长； 对于 MII6800Si/Pa，采用二进制步骤
• 分配器中的定长切割标记和激光卷尺长度可达 30m
• 高精度线性玻璃光栅尺
• 内置和粘贴光学索引和左/右限制
• 双向光学索引可重复至 1LSB
• 传感器功耗低、发热低
• 连接器中的状态 LED 使编码器状态一目了然

The Mercury II 6000 (MII6000) Series Encoders represents a breakthrough in performance, offering class-leading resolution and accuracy, digital output, the smallest sensor size, unmatched versatility, robustness, smart programmable features, and easy installation.

System Features at a Glance
• Mercury II 6000 Series Encoders consists of:
- MII6500/6700/6800 - A-quad-B Outputs
- MII6800Si/Pa (Pa - Panasonic) - High Speed Serial Interfaces
• Serial interface for Panasonic MINAS A4 and A5 series servo drives (for use with linear axes)
• High-resolution interpolated digital output directly from the sensor; resolution from 5µm to 1.2nm
• Extremely low cyclical error - only ± 20nm - provides smooth velocity control
• Small sensor - 8.2 mm tall sensor fits tight spaces (8.1 mm – 6000V)
• Faster - up to 5m/s at 0.1µm resolution (MII6000). Up to 10 m/s at 1.2nm resolution (MII6800Si/Pa)
• Smarter - programmable resolution in integer steps for MII6000; in binary steps for MII6800Si/Pa
• Cut-to-length Marker and Laser tape scale come in dispensers up to 30m
• Linear glass scales for high accuracy
• Built-in and Stick-on optical index and left/right limits
• Bi-directional optical index is repeatable to 1LSB
• Low power consumption, low heat generation at the sensor
• Status LEDs in connector show encoder status at a glance



MICROE编码器CE系列介绍及选型
ChipEncoder是一个模块化的数字接口SMT套件编码器系统，将小尺寸与高分辨率结合在一起。ChipEncoder型号具有内置插值功能，可直接安装在PC板上，通过设计集成可提供大量空间并节省成本。

• ChipEncoder打破了价格性能屏障，为运动控制设计带来了新的可能性
• 与PC板上的其他元件集成，实现低的总系统成本； 设计用于低成本自动化PC板组件
• 具有板载插补和数字输出的高分辨率提高了运动系统的精度和稳定性
• 高速能力增强了运动系统性能
• 非接触设计实现高可靠性
• 小尺寸实现了超微型、低成本的运动控制

ChipEncoder is a modular digital interface SMT kit encoder system that combines small size with high resolution. ChipEncoder models feature built-in interpolation and mount directly on your PC board, providing significant space and cost savings through design integration.

• ChipEncoder breaks the price performance barrier to open new possibilities for your motion control designs
• Integrates with other components on your PC board for lowest total system cost; designed for low cost automated PC board assembly
• High resolution with on-board interpolation and digital output improves motion system accuracy and stability
• High speed capability enhances motion system performance
• Non-contact design for high reliability
• Small size enables ultra-miniature, low cost motion control



MICROE编码器MII 1600系列介绍及选型
新型 Mercury II 1600 编码器代表了性能上的突破，速度快、传感器尺寸小、坚固耐用且易于安装，所有这些均采用定长切割卷尺。 连接器选项为 15 针标准 D-sub 或客户指定。

• A-quad-B 输出具有 5μm 至 0.5μm 分辨率和索引窗口
• 重复性等于分辨率
• 小型传感器 - 8.7 毫米高的传感器适合狭小空间
• 更快 - 高达 20m/s
• 定长切割激光卷尺装在分配器中，长度可达 30m
• 粘贴式双向光学索引
• 传感器内置高达 x40 插值
• 对水垢污染的高耐受性
• 使用对准工具 LED 实现广泛的对准公差和轻松设置
• 差分输出可在高 EMI 环境中实现高可靠性
• 用于编码器设置、监控和诊断的可用软件
• 符合 CE 和 RoHS 标准

The new Mercury II 1600 encoder represents a breakthrough in performance, offering high speed, small sensor size, robustness, and easy installation, all using cut-to-length tape scale. Connector options are 15 pin standard D-sub or customer specified.

• A-quad-B output with 5μm to 0.5μm resolution and index window
• repeatability equal to resolution
• Small sensor - 8.7mm tall sensor fits tight spaces
• Faster - up to 20m/s
• Cut-to-length laser tape scale comes in a dispenser in lengths up to 30m
• Stick-on bi-directional optical index
• Up to x40 interpolation built into the sensor
• High tolerance to scale contamination
• Broad alignment tolerances and easy setup using alignment tool LEDs
• Differential outputs for high reliability in high EMI environments
• Available software for encoder setup, monitoring, and diagnostics
• CE and RoHS compliant



MICROE编码器及配件常用型号：
MICROE M1000-M10-R1910-HA
MICROE M1000-M05-L55-C1
MICROE Mercury II 5530-AB-200-2-1-0
MICROE M20
MICROE MII6810-AB-16384-1-1-0
MICROE MII6710-AB-4000-1-1-0
MICROE MII6510-AB-400-1-1-0
MICROE MII6810-Si-14-21-1-0
MICROE MII6810-Pa-14-10-1-0
MICROE CE300-4
MICROE CE300-40
MICROE CE-40GC
MICROE CE300-40-PCB
MICROE CE300
MICROE 195-00294
MICROE 195-00295
MICROE 195-00296
MICROE TS-0001
MICROE MII5510-AB-200-2-1
MICROE MII5510-AB-200-4-1-0
MICROE MII5510-AB-400-1-1-0
MICROE MII5810-Pa-14-10-1-0
MICROE MII5810-Si-14-21-1-0
MICROE MII5710-AB-4000-1-1-0
MICROE MII5810-AB-16384-1-1-0
MICROE MII1600-40
MICROE MII1630S-4
MICROE MII1630S-8
MICROE MII1630S-20
MICROE MII1630S-40
MICROE L80
MICROE M1200-CA300C-200-L5-2
MICROE Mercury ll 1900
MICROE SS200X
MICROE Mercury 2000 SS-200C

如果您需要完整的MICROE的相关技术咨询，请随时致电爱泽工业，或者访问网站,我们将尽全力解决您的问题。
