爱泽工业2024年8月部分到货产品专题及库存——SUPERSEN篇

如下为我司爱泽工业IZE_Industries本月到货SUPERSEN相关产品，欢迎致电索取样本资料和产品信息。


SUPERSEN气弹簧A100261-A69P-150NB


SUPERSEN气弹簧SB1-185-A6-200N


SUPERSEN气弹簧SB2-205-L4-500N


SUPERSEN气弹簧SB2-245-C920M6-400N


SUPERSEN气弹簧SB2-430-L4-500N


SUPERSEN气弹簧SB3-585-C920M8-220N

SUPERSEN气弹簧0615系列介绍
• 自由型氮气缸气弹簧0615 系列系指轴心直径为6mm, 外管直径为15mm 的氮气缸，其压力介质为氮气(N2), 阻尼介质为液压油(OIL)，适用温度为-20℃ ~+80℃,允许长度公差范围为±3mm。

• 安装建议在机构门片展开时, 活塞杆轴心端向下安装*佳,能使门片于完全伸展开时具有缓冲
 功能.

• 压力及长度单位:
 9.8 牛顿(N)=1公斤(KG)=2.2磅(LBS)  /  长度单位(mm)

• 适用配件: BKT-11 / BKT-12

• Free-type nitrogen cylinder gas spring 0615 series refers to nitrogen cylinders with a shaft diameter of 6mm and an outer tube diameter of 15mm. Its pressure medium is nitrogen (N2), and the damping medium is hydraulic oil (OIL). The applicable temperature is -20℃ ~+80℃, and the allowable length tolerance range is ±3mm.

• Installation suggestion: When the mechanism door is unfolded, it is best to install the piston rod shaft end downward, which can make the door have a buffering function when it is fully extended.

• Pressure and length unit:
9.8 Newton (N) = 1 kilogram (KG) = 2.2 pounds (LBS) / length unit (mm)

• Applicable accessories: BKT-11 / BKT-12

SUPERSEN气弹簧0818系列
SUPERSEN 自由型安全开关氮气缸气弹簧0818 系列系指轴心直径为8 mm, 外管直径为18 mm 的氮气缸并于活塞杆外部加装套管扣环增加安全性,其压力介质为氮气( N2), 阻尼介质为液压油(OIL)，适用温度为- 20℃~+80℃,允许长度公差范围为±2mm。

SUPERSEN Free Type Safety Switch Nitrogen Cylinder Gas Spring 0818 series refers to a nitrogen cylinder with a shaft diameter of 8 mm and an outer tube diameter of 18 mm, and a sleeve ring is installed outside the piston rod to increase safety. Its pressure medium is nitrogen (N2), and the damping medium is hydraulic oil (OIL). The applicable temperature is -20℃~+80℃, and the allowable length tolerance range is ±2mm.

SUPERSEN气弹簧1022系列
• SUPERSEN 自由型氮气缸气弹簧1022 系列系指轴心直径为10mm, 外管直径为22mm 的氮气缸，其压力介质为氮气(N2), 阻尼介质为液压油(OIL)，适用温度为- 20 ℃~+80℃,允许长度公差范围为±2mm。

• SUPERSEN 自由型气弹簧(氮气缸) 规格品其轴心表面处理:氮化轴心/ 外管表面处理: 黑色烤漆 (其它颜色需求亦可制作)

• SUPERSEN free-type nitrogen cylinder gas spring 1022 series refers to nitrogen cylinders with a shaft diameter of 10mm and an outer tube diameter of 22mm. Its pressure medium is nitrogen (N2), and its damping medium is hydraulic oil (OIL). The applicable temperature is -20℃~+80℃, and the allowable length tolerance range is ±2mm.

• SUPERSEN free-type gas spring (nitrogen cylinder) specifications: shaft surface treatment: nitrided shaft/outer tube surface treatment: black paint (other colors can also be produced on request)

SUPERSEN气弹簧常用型号：
SUPERSEN A060181-A69P-27NB
SUPERSEN A060181-A69P-30NB
SUPERSEN A060181-A69P-55NB
SUPERSEN A060181-A69P-70NB
SUPERSEN A060181-A69P-85NB
SUPERSEN A060181-A69P-105N
SUPERSEN A060181-A69P-147NB
SUPERSEN A060181-A69P-150NB
SUPERSEN A060181-A69P-167NB
SUPERSEN A060181-A69P-186NB
SUPERSEN A060181-A69P-206NB
SUPERSEN A080221-A69P-50NB
SUPERSEN A080221-A69P-59NB
SUPERSEN A080221-A69P-80NB
SUPERSEN A080221-A69P-81NB
SUPERSEN A080221-A69P-100NB
SUPERSEN A080221-A69P-119NB
SUPERSEN A080221-A69P-120NB
SUPERSEN A080221-A69P-196NB
SUPERSEN A100261-A69P-69NB
SUPERSEN A100261-A69P-70NB
SUPERSEN A100261-A69P-79NB
SUPERSEN A100261-A69P-85NB
SUPERSEN A100261-A69P-88NB
SUPERSEN A100261-A69P-100NB
SUPERSEN A100261-A69P-147NB
SUPERSEN A100261-A69P-150NB
SUPERSEN A100261-A69P-196NB
SUPERSEN A100261-A69P-200NB
SUPERSEN A110281-A69P-75NB
SUPERSEN A110281-A69P-76NB
SUPERSEN A110281-A69P-110NB
SUPERSEN A110281-A69P-120NB
SUPERSEN A110281-A69P-147NB
SUPERSEN A110281-A69P-186NB
SUPERSEN A110281-A69P-196NB
SUPERSEN A110281-A69P-200NB
SUPERSEN SB1-106-A6-XXXN
SUPERSEN SB1-145-A6-XXXN
SUPERSEN SB1-185-A6-XXXN
SUPERSEN SB1-226-A6-XXXN
SUPERSEN SB1-265-A6-XXXN
SUPERSEN SB1-305-A6-XXXN
SUPERSEN SB1-365-A6-XXXN
SUPERSEN SB2-205-L4-XXXNPK
SUPERSEN SB2-245-L4-XXXNPK
SUPERSEN SB2-285-L4-XXXNPK
SUPERSEN SB2-295-L4-XXXNPK
SUPERSEN SB2-330-L4-XXXNPK
SUPERSEN SB2-375-L4-XXXNPK
SUPERSEN SB2-405-L4-XXXNPK
SUPERSEN SB2-430-L4-XXXNPK
SUPERSEN SB2-450-L4-XXXNPK
SUPERSEN SB2-485-L4-XXXNPK
SUPERSEN SB2-500-L4-XXXNPK
SUPERSEN SB2-525-L4-XXXNPK
SUPERSEN SB2-585-L4-XXXNPK
SUPERSEN SB2-630-L4-XXXNPK
SUPERSEN SB2-205-C920M6-XXXN
SUPERSEN SB2-245-C920M6-XXXN
SUPERSEN SB2-285-C920M6-XXXN
SUPERSEN SB2-295-C920M6-XXXN
SUPERSEN SB2-325-C920M6-XXXN
SUPERSEN SB2-330-C920M6-XXXN
SUPERSEN SB2-365-C920M6-XXXN
SUPERSEN SB2-375-C920M6-XXXN
SUPERSEN SB2-405-C920M6-XXXN
SUPERSEN SB2-430-C920M6-XXXN
SUPERSEN SB2-445-C920M6-XXXN
SUPERSEN SB2-450-C920M6-XXXN
SUPERSEN SB2-485-C920M6-XXXN
SUPERSEN SB2-500-C920M6-XXXN
SUPERSEN SB2-525-C920M6-XXXN
SUPERSEN SB2-585-C920M6-XXXN
SUPERSEN SB2-630-C920M6-XXXN
SUPERSEN SB3-240-C920M8-XXXN
SUPERSEN SB3-270-C920M8-XXXN
SUPERSEN SB3-285-C920M8-XXXN
SUPERSEN SB3-330-C920M8-XXXN
SUPERSEN SB3-385-C920M8-XXXN
SUPERSEN SB3-405-C920M8-XXXN
SUPERSEN SB3-450-C920M8-XXXN
SUPERSEN SB3-485-C920M8-XXXN
SUPERSEN SB3-500-C920M8-XXXN
SUPERSEN SB3-525-C920M8-XXXN
SUPERSEN SB3-585-C920M8-XXXN
SUPERSEN SB3-670-C920M8-XXXN
SUPERSEN SB3-685-C920M8-XXXN
SUPERSEN SB3-700-C920M8-XXXN
SUPERSEN SB3-750-C920M8-XXXN
SUPERSEN SB3-785-C920M8-XXXN
SUPERSEN SB3-830-C920M8-XXXN
SUPERSEN SB3-885-C920M8-XXXN

如果您需要完整的SUPERSEN的相关技术咨询，请随时致电爱泽工业，或者访问网站，我们将尽全力解决您的问题。
