爱泽工业2024年9月部分到货产品专题及库存——AUCOM篇

如下为我司爱泽工业IZE_Industries本月到货AUCOM相关产品，欢迎致电索取样本资料和产品信息。


AUCOM软启动器CSX-055-V4-C1


AUCOM软启动器CSX-090-V4-C1


AUCOM软启动器CSXI-022-V4-C1


AUCOM软启动器CSXi-075-V4-C1


AUCOM软启动器EMX4I-0135B-V7-C1-H

AUCOM软启动器CSX系列介绍及选型
紧凑的尺寸
CSX 是一种紧凑轻便的装置，因此适合安装在狭小空间内，是旧启动器的替代品。

易于使用调整
CSX 易于配置，只需三个简单的调整。选择初始启动电压、启动斜坡时间和停止斜坡时间（如果需要），启动器就可以运行了。旋转拨盘可实现可靠、可重复的配置，无需浏览菜单，也没有难以使用的拨码开关。

集成旁路接触器
集成旁路接触器通过减少选择和连接额外设备的需要来简化安装。因为接触器已经包含在启动器中，所以安装的整体尺寸也更小。在电机运行时旁路启动器可减少发热量，因此启动器通常无需额外通风即可安装。

Compact size
The CSX is a compact and lightweight unit, so it is suitable for installation in small spaces and is the ideal replacement for older starters.

Easy-to-use adjustments
The CSX is easy to configure, with three simple adjustments. Select the initial start voltage, start ramp time and stop ramp time (if required), and the starter is ready to go. Rotary dials allow reliable, repeatable confguration with no need to navigate through a menu and no difficult-to-use dip switches.

Integrated bypass contactors
Integrated bypass contactors simplify installation by reducing the need to select and connect additional equipment. Because the contactors are already contained within the starter, the overall size of the installation is also smaller. Bypassing the starter while the motor is running reduces the amount of heating, so the starter can usually be installed with no additional ventilation.



AUCOM软启动器CSXi系列介绍
体积小巧
CSXi 是一种紧凑轻便的装置，因此适合安装在狭小的空间内，是现有电机控制中心中旧启动器的替代品。

集成旁路接触器
集成旁路接触器通过减少选择和连接附加设备的需要来简化安装。由于接触器已包含在启动器中，因此安装的整体尺寸也更小。在电机运行时绕过启动器还可以减少热量，因此启动器通常可以安装在没有额外通风的情况下。

基本电机保护
除了软启动和软停止的好处，可以提高设备的使用寿命和效率，CSXi 还可以保护电机和负载在运行过程中免受损坏。

CSXi 模拟电机温度以防止操作过载，旁路过载保护可保护启动器免受严重的电流尖峰影响。启动器还监控启动所用的时间，如果电机无法在允许的时间内启动，则会跳闸，防止负载堵转。

CSXi 还可以防止电源频率和电流的波动以及不正确的安装。

Compact size
The CSXi is a compact and lightweight unit, so it is suitable for installation in small spaces and is the ideal replacement for older starters in existing motor control centres.

Integrated bypass contactors
Integrated bypass contactors simplify installation by reducing the need to select and connect additional equipment. Because the contactors are already contained within the starter, the overall size of the installation is also smaller. Bypassing the starter while the motor is running also reduces the amount of heating, so the starter can usually be installed with no additional ventilation.

Essential motor protection
In addition to the benefits of soft start and soft stop, which improve the operating life and efficiency of your equipment, the CSXi also protects your motor and load from damage during operation.

The CSXi models the motor's temperature to prevent against operational overload, and bypass overload protection safeguards the starter from severe spikes in current. The starter also monitors the time taken to start and will trip if the motor cannot start within the allowed time, protecting against stalled loads.

The CSXi also protects against fluctuations in mains frequency and current, as well as incorrect installation.

AUCOM软启动器EMX4i系列介绍及选型
EMX4i 软启动器为软启动技术设定了新标准。 EMX4i 不仅体积更小、功能更强大、具有新的控制和保护功能，而且还引入了改变规则的智能卡功能。 将智能卡安装到 EMX4i 上可将其从智能电机控制器转变为完整的系统控制器。

The EMX4i Soft Starter sets new standards for soft start technology. Not only is the EMX4i smaller, more powerful and packed with new control and protection features, it also introduces the game-changing Smart Card capability. Fitting a Smart Card to the EMX4i transforms it from super smart motor controller to complete system controller.



AUCOM软启动器常用型号：
AUCOM CSX-007-V4-C1
AUCOM CSX-007-V4-C2
AUCOM CSX-022-V4-C1
AUCOM CSX-030-V4-C1
AUCOM CSX-045-V4-C1
AUCOM CSX-055-V4-C1
AUCOM CSX-055-V4-C2
AUCOM CSX-075-V4-C1
AUCOM CSX-090-V4-C1
AUCOM CSX-110-V4 C1
AUCOM CSX-110-V4-C1
AUCOM CSX-110-V4-C1(C2)
AUCOM CSXi-007-V4-C1
AUCOM CSXi-007-V6-C1
AUCOM CSXi-015-41
AUCOM CSXi-015-V4-C1(C2)
AUCOM CSXi-015-V4-C2
AUCOM CSXi-018-V4-C1
AUCOM CSXi-022-V4-C1
AUCOM CSXi-022-V4-C2
AUCOM CSXi-030-V4-C1
AUCOM CSXi-030-V4-C2
AUCOM CSXi-030-V4-C3
AUCOM CSXi-037-V4-C1
AUCOM CSXi-045-41
AUCOM CSXI-045-V4-C1
AUCOM CSXi-055-V4-C1
AUCOM CSXi-075-V4-C1
AUCOM CSXI-090-V4-C1
AUCOM CSXI-110-V4-C1
AUCOM CSXI-110-V6-C1
AUCOM EMX3-0200B-V4-C1-H
AUCOM EMX3-0255B-4
AUCOM EMX3-0255B-411
AUCOM EMX3-0255B-V4-C1
AUCOM EMX3-0920B-V4-C1-H
AUCOM EMX4-1250B-V5-C1-HS
AUCOM EMX4E-0042B-V5-C1-H
AUCOM EMX4E-0200B-V5-C1-H
AUCOM EMX4E-0580B-V5-C1-H
AUCOM EMX4i-0024B-V5-C1-H
AUCOM EMX4i-0042B-V5-C1-H
AUCOM EMX4i-0052B-V5-C1-H
AUCOM EMX4i-0064B-V5-C1-H
AUCOM EMX4i-0069B-V5-C1-H
AUCOM EMX4i-0105B-V5-C1-H
AUCOM EMX4i-0115B-V5-C1-H
AUCOM EMX4i-0135B-V5-C1-H
AUCOM EMX4I-0135B-V7-C1-H
AUCOM EMX4I-0135-V5-C1-H
AUCOM EMX4i-0184B-V5-C1-H
AUCOM EMX4i-0200B-V5-C1-H
AUCOM EMX4i-0229B-V5-C1-H
AUCOM EMX4I-0250B-V5-C1-H
AUCOM EMX4i-0352B-V5-C1-H
AUCOM EMX4i-0397B-V5-C1-H
AUCOM EMX4i-0550B-V5-C1-H
AUCOM EMX4I0564EV12C2H
AUCOM EMX4I-0735C-511
AUCOM EMX4i-105B-V7-C1-H
AUCOM EMX4i-1070B-V5-C1-H

如果您需要完整的AUCOM的相关技术咨询，请随时致电爱泽工业，或者访问网站,我们将尽全力解决您的问题。
