爱泽工业2024年12月部分到货产品专题及库存——GF篇

如下为我司爱泽工业IZE_Industries本月到货GF相关产品，欢迎致电索取样本资料和产品信息。




GF流量计3-2551-P0-12




GF流量计3-2551-P1-12




GF流量计3-2551-P2-22




GF液位传感器3-2250-11U




GF传感器3-2751-3




GF电极3-2724-00

GF电磁流量计2551系列介绍
2551 型电磁流量计是一种插入式磁流量传感器，不具有任何活动部件。该传感器采用耐腐蚀材料设计，以*低的维护成本提供长期可靠性。材料选项包括 PP 和不锈钢、PVDF 和 Hastelloy-C 或 PVDF 和钛。利用 GF 安装配件的综合系列，传感器对准和插入深度是自动的。这些多功能、易于安装的传感器可在 DN15 至 DN900（½ 至 36 英寸）管道尺寸的宽动态范围内提供准确的流量测量，满足许多不同应用的要求。

2551 型电磁流量计提供多种输出选项，包括频率/数字 (S3L) 或 4 至 20 mA，可用于盲版和显示版。频率或数字 (S3L) 传感器输出可与 GF 的广泛流量仪表系列一起使用，而 4 至 20 mA 输出可用于直接输入到 PLC、图表记录器等。4 至 20 mA 输出和数字 (S3L) 传感器接口均可用于长距离信号传输。另一个好处是空管检测，当传感器未完全润湿时，该检测具有零流量输出。此外，频率输出是双向的，而 4 至 20 mA 输出可使用显示器或连接到 PC 以实现编程功能的 3-0252 配置工具设置为单向或双向流动。此外，2551 Magmeter 的显示版本配有继电器，具有永久和可重置的累加器值，可存储并显示在显示屏上。此外，显示屏包含多种语言，包括英语、西班牙语、德语、法语、意大利语和葡萄牙语菜单选项。

特点
• 包括 -X0、-X1 的测试证书
• 无移动部件
• 双向流动
• 空管检测
• 安装在管道尺寸 DN15 至 DN900（½ 至 36 英寸）中
• 操作范围 0.05 至 10 m/s（0.15 至 33 ft/s）
• 即使在肮脏的液体中也能准确测量
• 聚丙烯和 PVDF 固定螺母标准，Valox 可选
• 4 至 20 mA，数字（S3L），频率，继电器输出（仅显示）
• 无压降
• 耐腐蚀材料；PP 或 PVDF 与 SS、Hastelloy-C 或钛
• 提供多语言显示菜单

The type 2551 Magmeter is an insertion style magnetic flow sensor that features no moving parts. The sensor design is available in corrosionresistant materials to provide long-term reliability with minimal maintenance costs. Material options include PP with stainless steel, PVDF with Hastelloy-C, or PVDF with Titanium. Utilizing the comprehensive line of GF installation fittings, sensor alignment and insertion depth is automatic. These versatile, simple-to-install sensors deliver accurate flow measurement over a wide dynamic range in pipe sizes ranging from DN15 to DN900 (½ to 36 in.), satisfying the requirements of many diverse applications.

Type 2551 Magmeters offer many output options of frequency/digital (S3L) or 4 to 20 mA which are available on both the blind and display versions. The frequency or digital (S3L) sensor output can be used with GF ’s extensive line of flow instruments while the 4 to 20 mA output can be used for a direct input to PLCs, chart recorders, etc. Both the 4 to 20 mA output and digital (S3L) sensor interface is available for long distance signal transmission. An additional benefit is the empty pipe detection which features a zero flow output when the sensors are not completely wetted. Also, the frequency output is bi-directional while the 4 to 20 mA output can be set for uni- or bi-directional flow using the display or the 3-0252 Configuration Tool which connects to PCs for programming capabilities. In addition the display version of the 2551 Magmeter is available with relays and features permanent and resettable totalizer values which can be stored and seen on the display. Also, the display contains multilanguages with English, Spanish, German, French, Italian and Portuguese menu options.

Features
• Test certificate included for -X0, -X1
• No moving parts
• Bi-directional flow
• Empty pipe detection
• Installs into pipe sizes DN15 to DN900 (½ to 36 in.)
• Operating range 0.05 to 10 m/s (0.15 to 33 ft/s)
• Accurate measurement even in dirty liquids
• Polypropylene and PVDF retaining nuts standard, Valox optional
• 4 to 20 mA, digital (S3L), frequency, relay output (display only)
• No pressure drop
• Corrosion resistant materials; PP or PVDF with SS, Hastelloy-C, or Titanium
• Multi-language display menu available

GF液位传感器2250系列介绍
用于控制液位和深度的 GF 2250 静水液位传感器具有一体式注塑 PVDF 主体和陶瓷隔膜，在腐蚀性液体中具有出色的兼容性。利用静水压力，2250 可忽略来自蒸汽、泡沫或液体表面任何其他碎屑的虚假液位信号。两个压力范围可实现与客户传感需求相匹配的更佳分辨率。固态电路可消除漂移（无内部电位计）。

这些传感器具有专有数字 (S3L) 输出或 4 至 20 mA 输出。带有接头连接的延长电缆和毛细管以及客户提供的导管，可浸入工艺容器中。

优点/特点
• 液位和深度测量
• 4 至 20 mA 输出或数字 (S³L) 输出
• 齐平陶瓷隔膜
• 易于潜水安装
• 两种压力范围可供选择
• 标准接头连接、延长电缆和毛细管（10 m）

The GF 2250 Hydrostatic Level Sensor for level and depth control has a one-piece injection molded PVDF body and ceramic diaphragm for superior compatibility in corrosive liquids. Utilizing hydrostatic pressure, the 2250 disregards false level signals from steam vapors, foam or any other debris on the liquid surface. Two pressure ranges allow for optimal resolution matched to your sensing needs. Solid state circuitry eliminates drift (no internal potentiometers).

These sensors are available with a proprietary digital (S3L) output, or 4 to 20 mA output. The extended cable and capillary tubing with the union connection and a customer supplied conduit, allow submersion in process vessels.

Benefits/features
• Level and depth measurement
• 4 to 20 mA output or digital (S³L) output
• Flush ceramic diaphragm
• Easy submersible installation
• Choice of two pressure ranges
• Standard union connection, extended cable and capillary tubing (10 m)

GF传感器2751系列介绍
2751 型 pH/ORP 智能传感器电子设备配备 DryLoc® 连接器，是现场校准、超范围玻璃阻抗和破碎玻璃检测的解决方案，可提醒操作员探头故障或需要维护。
2751 具有两种不同的输出：双线 4 至 20 mA 环路输出，带可选 EasyCal 功能或数字 (S3L) 输出，允许更长的电缆长度，并与所有类型的 9900、9950-1/2*、9950-10/-11 仪器或盲区 4 至 20 mA 兼容。pH/ORP 智能传感器电子设备允许在实验室环境中校准电极并在现场安装预校准的探头，从而减少系统停机时间。启用存储芯片的电极将存储操作数据，例如*小和*大 pH/mV 读数、运行时间、*小和*大温度（仅限 pH），以进行故障排除和操作评估。要充分利用 2751 的所有功能和优势，请与 9900 型（第四代或更高版本）、9950 变送器或 0486 Profibus 浓缩器一起使用。2751 通过自动识别电极类型自行配置 pH 或 ORP 操作。可选的 EasyCal 功能允许简单的按钮校准，并包含用于视觉反馈的 LED 指示灯。
2751 pH/ORP 智能传感器电子设备可用于潜水和在线安装。可与 ½” 至 4” 的 GF 安装配件一起使用。

功能
• 探头健康监测、玻璃阻抗和破碎玻璃检测
• 内存芯片接口，允许传输校准、运行时间数据和制造信息
• 在线一体式安装和潜水安装版本
• 自动 pH 温度补偿
• 自动配置 pH 或 ORP 操作
• 可选 EasyCal 校准辅助装置，可自动识别 pH 缓冲液，适用于 4、7 和 10 pH 和 ORP 溶液：醌氢醌饱和 pH 4 或 7 缓冲液和 Light 溶液 +469 mV

The type 2751 pH/ORP Smart Sensor Electronics featuring the DryLoc® connector, is the solution for field-free calibration, out of range glass impedance and broken glass detection, alerting the operator to probe failure or maintenance needs.
The 2751 features two different outputs: a two-wire 4 to 20 mA loop output with optional EasyCal function or a digital (S3L) output which allows for longer cable lengths and is compat ible with all types 9900, 9950-1/2*, 9950-10/-11 instruments or in blind, 4 to 20 mA. The pH/ORP Smart Sensor Electronics will allow for calibration of electrodes in a laboratory setting and installation of pre-calibrated probes in the field, reducing system downtime. Memory chip enabled electrodes will store operational data such as minimum and maximum pH/mV readings, runtime, minimum and maximum temperature (pH only), for troubleshooting and operational evaluation. To take full advantage of all features and benefits of the 2751, use with types 9900 (Generation IV or later), 9950 Transmitter or 0486 Profibus Concentrator. The 2751 self-configures for pH or ORP operation via automatic recognition of the electrode type. The optional EasyCal feature allows simple push-button calibration and includes an LED indicator for visual feedback.
The 2751 pH/ORP Smart Sensor Electronics available for submersible and inline installations. Can be used with GF installation fittings ½” to 4”.

Features
• Probe health monitoring, glass impedance and broken glass detection
• Memory chip interface that allows for transferable calibration, runtime data, and manufacturing information
• In-line integral mount and submersible installation versions
• Automatic pH temperature compensation
• Auto configuration for pH or ORP operation
• Optional EasyCal calibration aid with automatic pH buffer recognition for 4, 7 and 10 pH and ORP solutions: quinhydrone saturated pH 4 or 7 buffers and Light’s Solution +469 mV

GF电极2724系列介绍
2724-2726 pH 和 ORP 电极是通用传感器，适用于各种应用。大面积 PE 参比结和通路的构造可提高总参比有效性并确保长使用寿命。
带有耐腐蚀镀金触点的 DryLoc® 连接器可轻松将传感器连接到配套的 2751 pH/ORP 智能传感器电子设备。坚固的 PPS 螺纹传感器主体和扁平 pH、球形 pH 或扁平 ORP 传感元件的选择可为各种应用提供广泛的化学和机械兼容性。
有两种可选的 pH 传感版本可供选择，HF 和 LC。HF 版本适用于痕量氢氟酸（2% 或更少）会腐蚀标准 pH 玻璃的应用。LC 版本可用于标称值为 20–100 μS/cm 的低电导率流体。
2724-2726 电极采用 O 形圈密封，可与 ½“ 至 4“ GF 安装配件一起使用。它们也可以直接安装到缩径三通中，DN20 至 DN100（¾ 至 4 英寸）。传感器尖端必须位于流道中。

特点
• UHMW 聚乙烯参比端
• 连接到 751 pH/ORP 智能传感器电子元件时，内存芯片可访问各种独特功能
• PPS 主体具有广泛的化学兼容性
• 特殊设计允许以任何角度安装，甚至倒置或水平安装
• 安装在 DN15 至 DN100（½ 至 4 英寸）的 GF 标准安装配件中
• ¾” NPT 或 ISO 7/1-R 3/4 螺纹传感器，用于 DN20 至 DN100（¾ 至 4 英寸）的减径三通
• 快速温度响应
• 球形和扁平 HF 耐玻璃可用于浓度低于 2% 的痕量 HF
• 低电导率传感器可用于 20–100 μS/cm 的液体

The 2724-2726 pH and ORP electrodes are general purpose sensors ideal for a wide range of applications. The large area PE reference junction and pathway is constructed to increase the total reference effectiveness and ensures long service life.
The DryLoc® connector with corrosion resistant gold plated contacts readily connects the sensor to the mating 2751 pH/ORP Smart Sensor Electronics. The robust PPS threaded sensor body and choice of flat pH, bulb pH, or flat ORP sensing elements allows a broad range of chemical and mechanical compatibility for a wide variety of applications.
There are two optional pH sensing versions available, HF and LC. The HF version is for applications where traces of hydrofluoric acid (2% or less) will attack standard pH glass. The LC version can be used for low conductivity fluids 20–100 μS/cm nominal.
The 2724-2726 electrodes incorporate o-ring seal for use with ½“ to 4“ GF Installation fittings. They can also be mounted directly into reducing tees, DN20 to DN100 (¾ to 4 inch). Sensor tip must be in flow path.

Features
• UHMW polyethylene reference junction
• Memory chip enabled for access to a wide range of unique features when connected to the 751 pH/ORP Smart Sensor Electronics
• PPS body for broad range of chemical compatibility
• Special design allows for installation at any angle, even inverted or horizontal
• Mounts in GF standard installation fittings from DN15 to DN100 (½ to 4 in.)
• ¾” NPT or ISO 7/1-R 3/4 threaded sensors for use with reducing tees DN20 to DN100 (¾ to 4 in.)
• Quick temperature response
• Bulb and flat HF resistant glass available for trace HF, in less than 2% concentration applications
• Low conductivity sensor available for liquids from 20–100 μS/cm

GF传感器电极常用型号：
GF 3-2551-P0-12
GF 3-2551-T0-12
GF 3-2551-V0-12
GF 3-2551-P0-22
GF 3-2551-T0-22
GF 3-2551-V0-22
GF 3-2551-P0-42
GF 3-2551-T0-42
GF 3-2551-V0-42
GF 3-2551-P1-12
GF 3-2551-T1-12
GF 3-2551-V1-12
GF 3-2251-P1-22
GF 3-2551-T1-22
GF 3-2551-V1-22
GF 3-2551-P1-42
GF 3-2551-T1-42
GF 3-2551-V1-42
GF 3-2551-P2-12
GF 3-2551-T2-12
GF 3-2551-V2-12
GF 3-2551-P2-22
GF 3-2551-T2-22
GF 3-2551-V2-22
GF 3-2551-P2-42
GF 3-2551-T2-42
GF 3-2551-V2-42
GF 3-2250-11L
GF 3-2250-110
GF 3-2250-21L
GF 3-2250-21U
GF 3-2250-11U-1
GF 3-2250-11L-1
GF 3-2250-21U-1
GF 3-2250-21L-1
GF 3-2751-1
GF 3-2751-1-025
GF 3-2751-1-050
GF 3-2751-1-100
GF 3-2751-2
GF 3-2751-3
GF 3-2751-3-025
GF 3-2751-3-050
GF 3-2751-3-100
GF 3-2751-4
GF 3-2724-00
GF 3-2724-01
GF 3-2726-00
GF 3-2726-01
GF 3-2726-HF-00
GF 3-2726-HF-01
GF 3-2726-LC-00
GF 3-2726-LC-01
GF 3-2724-10
GF 3-2724-11
GF 3-2724-HF-10
GF 3-2724-HF-11
GF 3-2726-10
GF 3-2726-11
GF 3-2726-HF-10
GF 3-2726-HF-11
GF 3-2726-LC-10
GF 3-2726-LC-11
GF 3-2725-60
GF 3-2725-61

如果您需要完整的GF的相关技术咨询，请随时致电爱泽工业，或者访问网站,我们将尽全力解决您的问题。
