爱泽工业2025年10月部分到货产品专题及库存——FDC破爆片篇

如下为我司爱泽工业IZE_Industries本月到货 FDC相关产品，欢迎致电索取样本资料和产品信息。

FDC破爆片KSROH-1

FDC破爆片KSRRK-1/2

FDC破爆片KSWSRV-1/2

FDC接头配件

FDC破爆片KSRC-8

FDC破爆片KSRO

FDC破爆片KSRRK系列介绍

设计

• 反向圆顶剪切型

• 安装在 FDC 标准支架上

• 集圆盘和刀头于一体

• 圆顶翻转时，通过安装在圆盘上的刀环进行剪切

产品特点

• 高度安全，耐腐蚀

• 适用于背压、真空和脉动工况

• 无需真空支撑

• 工作温度范围广

• 工作压力与破裂压力之间的差距小，圆盘使用寿命长

• 比 KSRR 更易于操作

Design

• Reverse Dome Shear Type

• It is used with installation on FDC standard holder

• It is integrated with Disc and Knife

• Shearing structure ruptured by knife ring attached to disc while dome is inverted

Product Features

• Highly safe and resistant to corrosion

• Favourable for counterpressure, vacuum and pulsation conditions

• Vacuum Support is needless

• Wide range of workable temperature

• Long life of disc as there is small gap between working pressure and rupture pressure

• Easier to handle than KSRR

FDC破爆片KSRC系列介绍

设计

• 复合材料圆顶斜座式

• 适用于安装在 FDC 标准支架上

• 复合材料/圆顶结构，顶盘加工切口破裂

• 由顶盘、密封盘和真空盘组成

产品特点

• 适用于液体或蒸汽介质环境

• 如果密封盘材质为 Tefl，则易受高温影响

• 适用于背压、真空和脉动工况

• 如有需要，可提供真空支撑

• 适用于中高压

• 耐腐蚀，具体取决于密封盘材质

• 温度范围受密封盘材质限制

• 精确的破裂性能和卓越的可靠性

Design

• Composite Dome Sloped Seat Type

• It is used with installation on FDC standard holder

• Composite/Dome structure ruptured by slit processed on Top disc

• It consists of Top disc, Seal disc and Vacuum disc

Product Features

• Suitable for liquid or steam media environments

• Vulnerability to high temperature in case that material of Seal disc is Tefl on

• Favorable for counterpressure, vacuum and pulsation conditions

• If any, Vacuum Support is available

• It is applied to medium/high pressure

• Resistant to corrosion according to Seal Disc materials

• Limited temperature range by Seal Disc material

• Precise rupture performance and excellent reliability

FDC破爆片KSRO系列介绍

设计

• 法兰复合扁平型

• 无需支架即可安装在法兰上

• 复合/扁平结构，顶盘加工切口破裂

• 由顶盘、密封盘和真空盘组成

KSROH

• 复合扁平型

• 与 KSRO 相同，但用于安装在 FDC 标准支架上

产品特点

• 适用于液体或蒸汽介质环境

• 如果密封盘材质为 Tefl，则易受高温影响

• 易受脉动影响

• 如有脉动，可提供真空支撑

• 主要应用于低压环境

• 耐腐蚀性能取决于密封盘材质

• 温度范围受密封盘材质限制

• 精确的破裂性能和卓越的可靠性

Design

• Composite Flat Type for Flange

• Used with installation on Flange without holder

• Composite/Flat structure ruptured by slit processed on Top disc

• It consists of Top disc, Seal disc and Vacuum disc

KSROH

• Composite Flat Type

• Same as KSRO, but used with installation on FDC standard holder

Product Features

• Suitable for liquid or steam media environments

• Vulnerability to high temperature in case that material of Seal disc is Tefl on

• Vulnerability to pulsation conditions

• If any, Vacuum Support is available

• It is applied to low pressure mainly

• Resistant to corrosion according to Seal Disc materials

• Limited temperature range by Seal Disc material

• Precise rupture performance and excellent reliability

FDC破爆片KSRSF系列介绍

设计

• 前向圆顶刻划型

• 适用于安装在 FDC 标准支架上

• 刻划结构，刻划损伤经过精确拉伸破裂

产品特点

• 主要应用于高压环境

• 安全性高，耐腐蚀

• 适用于背压、真空和脉动工况

• 无需真空支撑

• 工作温度范围广

• 工作压力与破裂压力之间的差距小，阀瓣寿命长

Design

• Forward Dome Scored Type

• It is used with installation on FDC standard holder

• Carved structure with Scored Damage processed precisely ruptured by tension

Product Features

• It is applied to high pressure mainly

• Highly safe and resistant to corrosion

• Favourable for counterpressure, vacuum and pulsation conditions

• Vacuum Support is needless

• Wide range of workable temperature

• Long life of disc as there is small gap between working pressure and rupture pressure

FDC破爆片常用型号：

FDC KSROF

FDC KSROH

FDC KSRRK-1

FDC KSRBK

FDC KSRBKH

FDC KSRC-8

FDC KSRO

FDC KSRO-10

FDC KSRO-2

FDC KSRO-24

FDC KSRO-3

FDC KSRO-8

FDC KSRO-8 EA

FDC KSROFD

FDC KSROH 1"

FDC KSROHD

FDC KSROL

FDC KSRR

FDC KSRRC

FDC KSRRCF

FDC KSRRCFD

FDC KSRRCH

FDC KSRRK 1/2"

FDC KSRRK-1 1/2

FDC KSRRK-1 1/4

FDC KSRRK-10

FDC KSRRK-12

FDC KSRRK-14

FDC KSRRK-16

FDC KSRRK-2

FDC KSRRK-2 1/2

FDC KSRRK-3

FDC KSRRK-4

FDC KSRRK-5

FDC KSRRK-6

FDC KSRRK-8

FDC KSRRKF

FDC KSRRKP-1

FDC KSRRKP-1/2

FDC KSRRKP-3/4

FDC KSRRL

FDC KSRRLD

FDC KSRSF

FDC KSRSR

FDC KSRST

FDC KSWSRV 1/2

FDC KSWSRV 1/2T

FDC KSWSRV-1/2

FDC RTD-3000 3/4

FDC KSRO-32

FDC KSRRK-1/2

FDC KSRRK-3/4

如果您需要完整的FDC的相关技术咨询，请随时致电爱泽工业，或者访问网站,我们将尽全力解决您的问题。
