如下为我司爱泽工业
IZE_Industries本月到货
HUNGER相关产品，欢迎致电索取样本资料和产品信息。
HUNGER密封FI 50x19
HUNGER密封GD1000K 85x67x43
HUNGER密封TDI 50x60x10
HUNGER密封TDI 220x240x16
HUNGER密封TDT 100x108x11.5
HUNGER密封AI 100/112x12
HUNGER密封FI系列介绍
HUNGER FI型密封主要用于活塞杆。它提供杆和壳体之间的导向和支承表面，并防止金属与金属之间的接触。
FI由非常耐磨和低摩擦的POM-PTFE Bronze复合物组成。它可以用于矿物油基液压油，水油乳液和耐火流体以及压缩空气。
它有一个U形的横截面，并与有角度的对接接头分开。它可以螺旋地向内压缩以便装配到杆壳体中，在那里弹回到相应的安装槽中。轴承槽布置将其固定以防止轴向移动。
HUNGER FI型密封可以用作彼此相邻排列的单环或多环。
Hunger bearing ring type FI is mainly used on piston rods. It provides guiding and bearing surfaces between rod and housing and prevents metal to metal contact between them.
The FI consists of an extremely abrasion-resistant and low-friction POM-PTFE Bronze compound. It can be used for hydraulic oil with a mineral oil base, for water-oil emulsions and for fire-resistant fluids as well as compressed air.
It has a U-shaped cross-section and is split with an angled butt joint. It can be spirally compressed inwards for fitting into the rod housing where it springs back out into corresponding installation grooves. The bearing groove arrangement secures it against axial movement.
The Hunger bearing rings can be used as single rings or multiple rings arranged adjacent to each other. The number of bearing rings depends on the expected side loads. The butt joints in adjacent bearings should be staggered.
Due to its excellent dry running properties the bearing ring FI can also be applied behind a rod seal opposite the pressure side.
HUNGER密封GD1000K系列介绍
HUNGER GD1000K型滑环活塞密封件用于密封和引导双作用液压缸上的活塞。 密封设计和使用的材料使其特别适合更剧烈的应用，例如工程机械油缸。
根据材料版本，可以密封各种液压油。
该密封件可以标准形式与矿物油和水基液体一起使用。 修改后的版本可与其他流体一起使用。
GD1000K由六部分组成，一个改性NBR异形弹性环，一个起密封圈作用的耐磨PTFE青铜化合物滑环，两个改性PUR侧向支撑环和两个耐压轴承环 POM-化合物。
The HUNGER slide ring piston seal type GD1000K is used to seal and guide pistons on double-acting hydraulic cylinders. The seal design and materials used make it particularly suitable for the most vigorous applications e.g. construction machine cylinders.
Depending on material version all kinds of hydraulic fluids can be sealed.
The seal can be used in standard form with mineral oils and water based fluids. Modified versions are available for use with other fluids.
The GD1000K consists of 6 parts, a special shaped elastic ring of a modified NBR, a slide ring of abrasion resistant PTFE-Bronze-Compound which acts as the sealing ring, two lateral support rings of modified PUR and two bearing rings of pressure-resistant POM-Compound.
HUNGER密封TDI系列介绍
用于内部密封的 HUNGER TDI 串联密封件是活塞杆密封件。
它可以与矿物油一起使用，也可以以改性形式与水基液体、耐火液体和压缩空气一起使用。
TDI 密封件由两部分组成：带密封唇的 PUR 外部弹性环和带密封边缘的耐磨 PTFE 青铜化合物内部滑环。 安装前，密封唇突出超过密封件的标称直径，安装后压在活塞杆上。 由此在零压力下提供有效的密封。
The HUNGER TDI tandem seal for inside sealing is a piston rod seal.
It can be used with mineral oils and in modified form with water base fluids, fire resistant fluids and com- pressed air.
The TDI seal consists of 2 parts, an external elastic ring of PUR with a sealing lip and an internal slide ring of abrasion resistant PTFE-Bronze-Compound with a sealing edge. Prior to fitting, the sealing lip protrudes beyond the nominal diameter of the seal and when fitted is pressed against the piston rod. Effective sealing is thereby provided at zero pressure.
HUNGER密封TDT系列介绍
TDT 型 HUNGER 串联密封设计用于与伸缩气缸配合使用。 它可以与矿物油或压缩空气一起使用。
TDT 密封件采用 PUR 制造，内部有两个密封唇。 在安装之前，这些唇缘突出超过密封件的标称直径。 安装后，密封压缩迫使唇部抵住伸缩缸级，从而在零压力下提供密封功能。
The HUNGER tandem seal type TDT is designed for use with telescopic cylinders. It can be used with mineral oils or compressed air.
The TDT seal is manufactured in PUR and has two sealing lips on the inside. Prior to fitting, these lips protrude beyond the nominal diameter of the seal. Following installation, seal compression forces the lips against the telescopic cylinder stages, thereby providing a sealing function at zero pressure.
HUNGER 防尘圈Al系列介绍
HUNGER 防尘圈 Al 型具有阻挡极细灰尘、金属颗粒、沙粒等的功能，这样其后面的轴承元件和密封件就不会因污染物进入而过早磨损。
Al 刮水器可与矿物油和许多其他类型的液压油一起使用。
特殊版本可在高环境温度下使用。
必须小心确保雨刮器内部不会积聚压力，包括润滑脂压力。
The HUNGER wiper ring type Al has the function to keep out extremely fine dust, metal particles, grains of sand etc. such that the bearing elements and seals behind it are not subjected to premature wear as a result of contaminant ingress.
The Al wiper can be used with mineral oils and many other types of hydraulic fluid.
Special versions are available for use at high ambient temperatures.
Care must be taken to ensure that there is no pressure build-up, including grease lubricant pressure, on the inside of the wiper.
HUNGER密封常用型号：
HUNGER FI 32
HUNGER FI 40*19
HUNGER FI 50x56x19
HUNGER FI 60*24
HUNGER FI 60/71X3.9
HUNGER FI 65/76X3.9
HUNGER FI 70x24
HUNGER FI 90x24
HUNGER FI 130*24
HUNGER FI 140×24
HUNGER FI 250*33
HUNGER FI 320*35
HUNGER GD1000K 50*34*32
HUNGER GD1000K 63/47*39
HUNGER GD1000K 70*54*32
HUNGER GD1000K 70/54*39
HUNGER GD1000K 85*67*22.5/43
HUNGER GD1000K 150/128x53
HUNGER GD1000K 180/158*57
HUNGER GD1000K 200/175*64
HUNGER GD1000K 220/195*71
HUNGER GD1000K 280/255*85
HUNGER GD1000K 330*300*80
HUNGER GD1000K 350/320*80
HUNGER GD1000K 420*390*80
HUNGER GD1000K 440*410*80
HUNGER GD1000K 450*80
HUNGER GD1000K 500/470*80
HUNGER GD1000K 540/510/80
HUNGER GD1000K 750/720*80
HUNGER GD1000k 900/870/80
HUNGER TDI 28/36*7
HUNGER TDI 30/38*7
HUNGER TDI 36*44*8
HUNGER TDI 40/48*8
HUNGER TDI 45*55*10
HUNGER TDI 50/60*10
HUNGER TDI 60/75*12
HUNGER TDI 60*75*16
HUNGER TDI 70/85x12
HUNGER TDI 75*85*12
HUNGER TDI 90/105*12
HUNGER TDI 95*110*12
HUNGER TDI 125*145*16
HUNGER TDI 130/150*16
HUNGER TDI 140/155*17
HUNGER TDI 360/390*20
HUNGER TDI 400*430*20
HUNGER TDI 600/640*25
HUNGER TDT 80/88*11,5
HUNGER TDT 80/90*11,5
HUNGER TDT 81/89*11,5
HUNGER TDT 85/93*11,5
HUNGER TDT 85/97*11,5
HUNGER TDT 86/94*11,5
HUNGER TDT 87/95*11,5
HUNGER TDT 90/98*11,5
HUNGER TDT 95/103*11,5
HUNGER TDT 96/104*11,5
HUNGER TDT 96/106*11,5
HUNGER TDT 97/105*11,5
HUNGER TDT 98/106*11,5
HUNGER TDT 100/108*11,5
HUNGER TDT 103/111*11,5
HUNGER TDT 105/113*11,5
HUNGER TDT 107/115*11,5
HUNGER TDT 108/116*11,5
HUNGER TDT 110/118*11,5
HUNGER TDT 113/121*11,5
HUNGER TDT 114/124*11,5
HUNGER TDT 115/123*11,5
HUNGER TDT 118/126*11,5
HUNGER AI 22/30*7
HUNGER AI 25/33*7
HUNGER AI 28/36*7
HUNGER AI 30/38*7
HUNGER AI 32/40*7
HUNGER AI 35/43*7
HUNGER AI 36/44*7
HUNGER AI 40/48*7
HUNGER AI 42/50*7
HUNGER AI 45/55*7
HUNGER AI 48/56*7
HUNGER AI 50/60*7
HUNGER AI 52/60*7
HUNGER AI 55/65*7
HUNGER AI 56/66*7
HUNGER AI 60/70*7
HUNGER AI 63/73*7
HUNGER AI 65/75*7
HUNGER AI 68/76*7
HUNGER AI 70/80*7
如果您需要完整的
HUNGER的相关技术咨询，请随时致电爱泽工业，或者访问网站,我们将尽全力解决您的问题。
